Pneumatic wire stripping machine WPM-305
Pneumatic wire stripping machine WPM-305 Thumb

Pneumatic wire stripping machine WPM-305

  • Model No: WPM-305

  • Experience powerful pneumatic wire stripping with the Pneumatic Wire Stripping Machine WPM-305. Utilizing pneumatic force, this machine delivers fast and efficient stripping for various wire types. Ideal for high-volume stripping and demanding applications. Get robust wire stripping performance with pneumatic power and speed!

  • Inquiry now

Detailed description

Compact & Precise Pneumatic Wire Stripping Machine for Short, Small-Diameter Cables - Model WPM-305

The WPM-305 Pneumatic Wire Stripping Machine is a compact and highly precise solution designed for efficiently stripping short cables with small diameters. Featuring an ergonomic bevel design for comfortable operation, this machine incorporates a reliable dual-driving cylinder system that eliminates spring breakage, ensuring long-term durability. The integrated self-feeding oil and supply mechanism provides automatic lubrication to the cylinder, minimizing wear and extending the machine's lifespan. With a special sliding holder, the WPM-305 delivers a balanced stroke and high peeling precision. The electric control system allows for easy operation, and the adjustable structure accommodates various small wire thicknesses. This machine is ideally suited for processing short cables with small diameters, such as AC/DC power wires, computer cables, electronic cables, and multi-core cables.

Key Features and Benefits:

  • Ergonomic Bevel Design: Ensures comfortable operation according to ergonomic principles.
  • Dual-Driving Cylinder: Provides reliable and consistent performance without spring breakage.
  • Automatic Lubrication: The self-feeding oil system extends the machine's lifespan and reduces maintenance.
  • High Peeling Precision: Special sliding holder ensures a balanced stroke and accurate stripping results.
  • Electric Control: Offers easy and precise operation through electric controls.
  • Adjustable Structure: Allows for quick and easy adjustments to accommodate different small wire thicknesses.
  • Ideal for Short Cables: Specifically designed for efficient stripping of short cable lengths.
  • Suitable for Small Diameters: Perfect for processing wires and cables with diameters up to 5mm.
  • Pneumatic Power: Utilizes pneumatic force for powerful and consistent stripping action.
  • Compact Size: With dimensions of L400W300H270mm, it saves valuable workspace.
  • Lightweight: Weighing only 20KG, it's relatively easy to move and set up.

Detailed Functionality:

The WPM-305 Pneumatic Wire Stripping Machine utilizes a precise pneumatic system to efficiently remove the insulation from short cables with small diameters. The ergonomic bevel design ensures operator comfort, while the dual-driving cylinder guarantees reliable and consistent performance. The integrated automatic lubrication system minimizes maintenance needs. The adjustable structure allows users to easily adapt the machine to different small wire gauges and insulation thicknesses. The electric control system provides a user-friendly interface for efficient operation.

Specifications:

  • Model: WPM-305
  • Stripping Length: 50mm (Maximum stripping length)
  • Wire Diameter: 0-5mm
  • Air Pressure: 0.3-0.7mpa
  • Voltage: 220V/50HZ or 110V/60HZ (Please specify preference)
  • Force: 31-73KG
  • Weight: 20KG
  • Size: L400 * W300 * H270mm

Applications:

This machine is commonly used for stripping:

  • Short AC/DC power wires
  • Short computer cables
  • Short electronic cables
  • Short multi-core cables
  • Other short wires and cables with diameters up to 5mm.

Why Choose the WPM-305 Pneumatic Wire Stripping Machine?

The WPM-305 offers a compact, precise, and efficient solution for stripping short cables with small diameters. Its ergonomic design, durable construction, automatic lubrication, and adjustable settings make it an excellent choice for businesses needing to process smaller gauge wires in limited spaces.

Contact Us Today for a Quote!

Upgrade your short cable processing capabilities with the WPM-305 Pneumatic Wire Stripping Machine. Contact us today to learn more about this efficient and reliable machine and request a personalized quote. Please specify your desired voltage (220V or 110V) when contacting us.

Keywords: Pneumatic wire stripping machine, wire stripping machine, cable wire stripping machines, cable peeling machine, short cable stripper, small diameter wire stripper, WPM-305.



Model

WPM-305

WPM-310

WPM-315

WPM-330

WPM-416

Wire Size

1 - 5mm

1 - 10mm

1 - 15mm

1 - 20mm

1 - 30mm

Stripping Length

3 - 50mm

3 - 100mm

3 - 150mm

3 - 330mm

3 - 150mm

Cylinder Dia.

Ø40

Ø50

Ø60

Ø60

Ø80

Force

31-37Kg

49-115Kg

84-196Kg

84-196Kg

165-300Kg

Power Supply

220V

220V

220V

220V

220V

Dimension

40×30×27cm

48×33×28cm

60×42×36cm

110×55×45cm

80×62×55cm

Net. Weight

20Kg

25Kg

35Kg

65Kg

50Kg

Packing

Packed in Wood Case (Standard Export Packing)

Manual Wire Stripping Machine,Pneumatic Wire Stripping Machine,Wire Stripper






Manual Wire Stripping Machine,Pneumatic Wire Stripping Machine,Wire Stripper

blades of Manual Wire Stripping Machine,Pneumatic Wire Stripping Machine,Wire Stripper

blades of Manual Wire Stripping Machine,Pneumatic Wire Stripping Machine,Wire Stripper

FAQ:

1 Price terms

The price is based on EXW/FOB, if you request CFR or CIF, please give us your delivery port, and we will give you the CFR price or CIF price for reference.

2. What is your main market?

There are kinds of different clients from Asia, Africa, America, and Europe market.

3 . Could provide a professional solution based on our product?

We always promote suitable solutions based on products and satisfy clients with cost-down requirements.

4 Can we provide the sample for testing?

Yes, It will be a pleasure if u provide us with the sample for testing.

5 Do u test all goods before delivery?

Yes,100% test before shipment.

™ products are tested and guaranteed to keep in good quality with one year warranty excluding consumable parts.
If any main parts have quality problems, we will provide new parts and send them to you to change at once with detailed technical support and video illustration, or our experience engineer help to solve them. All problems and questions can be responded to within 24 hours after receiving email/phone/other chatting tools.
