Fully Automatic Cable Crimping Machine for Various Terminals WPM-555
Model No: WPM-555
Crimp various terminals fully automatically with the Fully Automatic Cable Crimping Machine for Various Terminals. This machine is designed to crimp a wide range of terminals fully automatically, providing versatile and efficient crimping capabilities. Ideal for diverse terminal crimping applications and full automation. Experience total automation for crimping various terminals with a versatile machine!
Fully Automatic Cable Crimping Machine for Multi-Core Sheathed Cables with Variable Lengths & Different Terminals (Model WPM-555)
The WPM-555 Fully Automatic Cable Crimping Machine is a cutting-edge solution designed for high-efficiency processing of 3-core and 4-core sheathed power cords. This advanced machine excels at automatically cutting, stripping, and crimping wires with inconsistent lengths (0-200mm difference) and can simultaneously crimp different terminals onto different inner core wires. This level of automation and flexibility makes the WPM-555 an ideal choice for manufacturers seeking to optimize their production processes and achieve exceptional precision.
Key Features and Advantages:
Fully Automatic Operation: Automates the entire process of cutting, stripping, and crimping for increased productivity.
Handles Multi-Core Sheathed Cables: Specifically designed for processing 3-core and 4-core power cords.
Processes Inconsistent Wire Lengths: Capable of handling wires with a length difference of 0-200mm.
Crimps Different Terminals Simultaneously: Can crimp various terminal types onto different inner core wires at the same time.
High Precision with Mitsubishi Servo Motors: Features three Mitsubishi servo motors and a ball screw drive for precise wire feeding, stripping, and terminal crimping.
Smooth Movement Connection: Ensures seamless transitions between wire feeding, stripping, and crimping stages.
User-Friendly Touch Screen Control: Simple and convenient mechanical control operated entirely via a touch screen interface.
Easy Data Adjustment: Allows for quick adjustments to stripping length, cutting length, cutting depth, and crimping position through the touch screen.
Wide Range of Applicable Terminals: Compatible with ground ring terminals, push-in 187/250 terminals, and flag shape terminals (horizontal terminal customization available).
Automatic Defect Detection: Effectively controls the occurrence of defective products by automatically detecting and allowing for immediate processing.
Detailed Functionality:
The WPM-555 Fully Automatic Cable Crimping Machine streamlines the production of multi-core sheathed cables with varying inner core lengths and terminal requirements. The machine automatically feeds the cable, precisely cuts it to the programmed length (accommodating length differences between cores), strips the outer sheath and inner core insulation to the specified lengths, and then simultaneously crimps different pre-selected terminals onto the designated inner core wires. The entire process is controlled through an intuitive touch screen interface, allowing for easy adjustments and monitoring. The integrated automatic detection system helps to identify and manage any potential defects, ensuring high-quality output.
Applicable Terminals:
Ground Ring Terminals
Push-in 187 Terminals
Push-in 250 Terminals
Flag Shape Terminals (Horizontal terminal customization available)
Applications:
This fully automatic cable crimping machine is ideal for a wide range of applications, including:
Manufacturing of power cords for various appliances
Production of wiring harnesses with specific terminal configurations
Assembly of multi-core cables with varying inner core lengths
Why Choose the WPM-555 Fully Automatic Cable Crimping Machine?
The WPM-555 offers unparalleled efficiency and precision for processing multi-core sheathed cables with variable lengths and diverse terminal requirements. Its full automation, combined with advanced servo motor technology and user-friendly touch screen control, significantly reduces manual labor, increases production speed, and ensures consistent, high-quality results. The ability to handle inconsistent lengths and crimp different terminals simultaneously provides exceptional flexibility for complex wiring configurations. The integrated defect detection system further enhances the reliability of your production process.
Optimize your multi-core cable processing with the WPM-555 Fully Automatic Cable Crimping Machine. Contact us today to learn more and request a personalized quote.
