Braided Sleeving Wrap-around Threading Machine for Wire and Cable
Braided Sleeving Wrap-around Threading Machine for Wire and Cable Braided Sleeving Wrap-around Threading Machine for Wire and Cable Braided Sleeving Wrap-around Threading Machine for Wire and Cable Braided Sleeving Wrap-around Threading Machine for Wire and Cable
  • Braided Sleeving Wrap-around Threading Machine for Wire and Cable

  • item No :
  • This automatic braided sleeving wrap-around machine is suitable for threading woven sleevings onto wire harness and cables.
  • Inquiry now

Detailed description


This automatic braided sleeving wrap-around machine is suitable for threading woven sleevings onto wire harness and cables.

This automatic braided sleeving wrap-around machine fuses the woven sleeving according to the set length and send it to the side of the hollow guiding tube for threading.
Fast speed, good threading effect, simple operation and precise cutting
Suitable for wrapping-around different types of braided sleevings onto wire harness and cables
It consists of a fine-tunable photoelectric control system and a PLC control system. The cutting length can be set, and the cutting performance is stable.
Applicable products: automotive wiring harness, electronic wire, medical wire, metal, wire and cable, etc.
Applicable industries: wire harness processing plant, electronics factory, electrical appliances, hardware, etc.


Model

WPM-BZ1

Applicable sleeving

fiber sleeving (woven mesh sleeving), melt cut materials

Applicable wire range

custom type (the wire diameter does not exceed the pipe diameter)

Applicable guide tube range

diameter 12-25mm

Cutting accuracy

±3MM

Cutting length

100mm-1200mm

Speed

no less than 1000PCS/hour (depending on sleeving size and manual operation speed)

Power

single phase AC 220V/50HZ

Energy consumption

400W/Hr

Operating ambient temperature

-5 ° C ~ +40 ° C

Relative humidity

(40 ~ 90)% RH

Access gas source

0.4~0.6MPA

Weight

about 80KG

Dimension

500W*1230L*1115H(mm) (subject to actual production)

Note

Special materials can be customized.
